Ruidong Group has successfully delivered a customized integrated heat pump room to the Jilin Oilfield transfer station of China National Petroleum Corporation. The room will serve the supply of hot water to the wellbore and provide a heat source for the seepage transmission system. The equipment is specially customized and integrated, including a heat pump unit, a hot water circulating pump, a high-temperature side circulating pump, and a heat exchanger.
Addressing the pain points of high energy consumption, large emissions, complex operation and maintenance, and high safety risks in transfer stations, Ruidong Group's industrial heat pumps have mature applications, integrating heat pumps, providing explosion-proof adaptation, insulation design, and remote monitoring to ensure the low-carbon, energy-saving, and stable operation of transfer stations.
The integrated heat pump room is set up outdoors to meet the needs of outdoor production, such as windproofing, waterproofing, and dustproofing. The insulation measures adopted meet the requirements for cold protection in extremely cold conditions, and it is equipped with remote transmission capabilities for valves, temperature, pressure, and flow meters.
Integrated heat pump room power distribution interface: Integrated electrical distribution box; Skid Instrument Interface: Integrated control cabinet(Equipment body, valves, and process pipelines are insulated)
Heat Pump Unit: One unit Rated Heating Capacity: 2250kW
Well Hot Water Circulation Pump: Two units Single pump flow rate: 150m³/h
High Temperature Circulation Pump: Two units Single pump flow rate: 220m³/h
Permeation Shell-and-Tube Heat Exchanger: One unit
Several heat pump supporting systems
Skid-mounted integrated system: Factory pre-assembled, quick on-site installation, shortening construction time and reducing construction risks.
High efficiency and energy saving: Waste heat utilization, high energy efficiency ratio, significantly reducing costs compared to traditional methods.
Environmental adaptability: Cold-resistant, corrosion-resistant, and reliable in operation, meeting continuous operation conditions in the field.
Safe and environmentally friendly: No open flame, low emissions, meeting safety production and environmental protection requirements.
Integrated Heat Pump Machine Room undergoes factory inspection to ensure quality, airtightness testing to ensure airtightness, and operational commissioning to ensure the control system is up to standard. Integrated Heat Pump Machine Room is transported modularly, with full logistics tracking, on-site installation and commissioning guidance, and comprehensive lifecycle operation and maintenance support.
Ruidong Group is deeply involved in the field of HVAC and industrial heat pumps. It is a national high-tech enterprise that integrates R&D, production, sales and service, and focuses on providing efficient and energy-saving heat source solutions for industrial, commercial and other fields.
